Brinno BCC200 Time Lapse Construction Camera Bundle
Brinno BCC200 Time Lapse Construction Camera Bundle
Our best selling camera and weather resistant housing, combined with accessories to allow you to capture your project out of the box.
- TLC200 Pro 720p HD time-lapse camera kit
- Weather resistant housing and bracket
- 80 day battery life, with a capture every 10 minutes using the timer
- 1/3" Low Light HDR Sensor; 4.2um Pixels
- CS Lens Mount
- 19mm, f/2.0, 112° Wide Lens Included
- SD Memory Card Storage
- Powered by 4 x AA Batteries
- Time Lapse Intervals from .3 Sec (ASAP) - 24 h
Brinno TLC200 Pro camera, weather resistant housing and mounting bracket. The included bracket is intended for light duty use and not recommended for long term construction projects which often require a simple sturdy custom mount.
BCC200 Sample Videos
The Brinno TLC200 Pro camera offers a High Dynamic Range (HDR) imaging sensor which allows you to make the best video in any given lighting situation. From intense backlight to dusk the Brinno Pro will deliver great results.
Features
 |
HDR Video Sensor High performance HDR video sensor, which helps produce great shots with high contrast, even in challenging lighting conditions like those encountered at night |
 |
Instant Video The Brinno BCC200 produces completed time lapse video files, not thousands of separate photos, no complicated post-processing! |
 |
Amazing Battery LIfe Using the timer feature to only record working hours, batteries will last 2.5 months with a capture every 10 minutes. |
 |
Construction from Start to Finish Capture everything from a kitchen remodel to a skyscraper. View months or years of work in minutes. |
 |
f/2.0 Aspherical lens Sharper, brighter images with this aspherical glass lens. |
 |
Weather Resistant IPX4 dustproof weather resistant housing design. Use indoors to keep construction dust off your camera or oudoors to keep the rain away. |
Specifications
| Camera | ||
| Model | TLC 200 Pro | |
| LCD Screen |
1.44" TFT LCD | |
| Waterproof | Optional, (with the Weather Resistant Housing (ATH120)) | |
| Capture Mode | ||
| Time Lapse |
Auto generation of Time Lapse video |
|
| Stop Motion |
Optional, ( with the Shutter Line (ATS110)) |
|
| Motion Activated | Optional, ( with the Motion Sensor (ATM100) and Weather Resistant Housing (ATH120)) | |
| Image Sensor | ||
| Type | 1/3" HDR sensor | |
| Dynamic Range | 115db | |
| Resolution | 1.3 Mega pixel | |
| Pixel size | 4.2um | |
| Sensitivity | 3650mV/lux-sec (Ultra good low light quality) | |
| Optics Lens (BCS 019) | ||
| Type |
CS Mount (Aspherical Glass Lens) |
|
| Aperture |
F 2.0 |
|
| Field of View |
112° |
|
| Focal Length |
19 mm (35mm equivalent) |
|
| Focus Distance | Manual focus from 1 cm to ∞ (factory setting: 40 cm ) | |
| Shooting Setting | ||
| Scene | Daylight, Twilight, Night, Moon, Star | |
| White Balance | Auto, Day, Shade, Cloudy, Fluorescent Light (Cool), Fluorescent Light (Warm), Tungsten Light | |
| Custom Image | Exposure, Saturation, Contrast, Sharpness | |
| Recording |
||
| Time Lapse Video | Format: AVI | |
| Resolution: 1280x 720 |
||
| Still Image | Format: JPEG (only for using Shutter Line) | |
| Resolution: 1280x 720 |
||
| Memory Storage | SD Card (Supported up to 32 GB) | |
| Time Interval |
||
| ASAP |
Captures 3~ 5 photos in 1 second |
|
| Custom | From 1 second to 24 hours | |
| Power |
||
| Power source | Battery: 4 AA Batteries |
|
| DC IN: 5V (Micro USB connector) |
||
| Battery Life | 2 second time interval, captures 240,000 frames |
|
| Camera Body Dimension |
||
| Size (DxWxH) |
64x 52x 107 mm |
|
| Weight |
140 g (without batteries) |
|
| Color | Black | |
The battery life depends on different scene settings
| Scene | Daylight | |
| Time interval | Frames captured | Days |
| ASAP | 168000 | 1 |
| 1 sec | 200000 | 2.3 |
| 2 sec | 244000 | 5.6 |
| 5 sec | 204000 | 11.5 |
| 10 sec | 145000 | 17.0 |
| 20 sec | 108000 | 25.0 |
| 30 sec | 84500 | 29.0 |
| 1 min | 51000 | 35.0 |
| 5 min | 12300 | 42.0 |
| 10 min | 6300 | 43.0 |
| 1 Hr | 1070 | 44.0 |
| 4 Hr | 269 | 44.0 |
| 24 Hr | 45 | 45.0 |
| Scene | Twilight | |
| Time interval | Frames captured | Days |
| 2 sec | 67400 | 1.6 |
| 5 sec | 55500 | 3.2 |
| 10 sec | 51300 | 5.9 |
| 20 sec | 51000 | 11.5 |
| 30 sec | 45000 | 15.0 |
| 1 min | 33700 | 23.0 |
| 5 min | 10900 | 38.0 |
| 10 min | 5900 | 41.0 |
| 1 Hr | 1060 | 44.0 |
| 4 Hr | 269 | 44.0 |
| 24 Hr | 45 | 45.0 |
| Scene | Night | |
| Time interval | Frames captured | Days |
| 5 sec | 39000 | 2.3 |
| 10 sec | 30000 | 3.5 |
| 20 sec | 28100 | 6.5 |
| 30 sec | 26200 | 9.0 |
| 1 min | 21800 | 15.0 |
| 5 min | 9300 | 32.0 |
| 10 min | 5400 | 37.0 |
| 1 Hr | 1040 | 43.0 |
| 4 Hr | 268 | 44.0 |
| 24 Hr | 44 | 44.0 |
| Scene | Moon | |
| Time interval | Frames captured | Days |
| 7 sec | 18300 | 1.5 |
| 10 sec | 18800 | 2.2 |
| 20 sec | 16000 | 3.5 |
| 30 sec | 15500 | 5.0 |
| 1 min | 13800 | 9.0 |
| 5 min | 7400 | 25.0 |
| 10 min | 4700 | 32.0 |
| 1 Hr | 1000 | 42.0 |
| 4 Hr | 266 | 44.0 |
| 24 Hr | 44 | 44.0 |
 |
 |
 |
 |
|
| Model | TLC200 | TLC200 f1.2 (BCC100) | TLC200 Pro (BCC200) | TLC120 |
| Color | White/Green | Black/Green | Black | TLC120 - Orange/Black TLC120A - Black |
| Viewfinder | 1.44" LCD | 1.44" LCD | 1.44" LCD | App |
| Image sensor | 1.3 MP | 1.3 MP | 1.3 MP HDR | 1.3 MP HDR |
| Resolution | 1280 x 720 (16:9) | 1280 x 720 (16:9) | 1280 x 720 (16:9) | 1280 x 720 (16:9) |
| Aperture | f/2.8 | f/1.2 | f/2.0 | f/2.0 |
| Focal length (mm) | 36 | 18 (35mm equivalent) | 19 (35mm equivalent) | 19 (35mm equivalent) |
| Field of view | 59° | 112° (720P) | 112° (720P) | 112° (720P) |
| Aspherical lens |  |
|
|
|
| Interchangeable CS mount lens | |
|||
| HDR video | |
|
||
| Scene setting | |
|
||
| White balance | |
|
||
| Micro USB output | |
|
||
| Webcam function | |
|
||
| Wi-Fi | Wi-Fi (802.11 b/g) | |||
| Bluetooth | BLE 4.0 | |||
| Brinno App | Android 4.4+/ iOS 7.0+ | |||
| Extension port | |
|
|
|
| Time interval | 0.5 sec, 1 sec-24 hrs | 0.5 sec, 1 sec-24 hrs | 0.3 sec, 1 sec-24 hrs | |
| Battery life | 270,000 photos | 270,000 photos | 240,000 photos | |
| Storage media | SD/SDHC card | SD/SDHC card | SD/SDHC card | |
| Media included | 2GB | 4GB | 4GB | 8GB |
| Maximum storage | 32GB (Larger cards may work if formatted from exFAT to FAT-32) | |||
| Video format | AVI | |||
| Weather resistant | With optional housing ATH110 | With optional housing ATH120 | IPX4 |
|
| Stop motion video | With optional shutter release cable | |||
| Still images (JPEG, 1280 x 720) | Can be extracted with the Brinno Video Player (PC only) available at the bottom of the Brinno Download Page. | |||
| Batteries required | 4 AA (included) | Rechargable | ||
| External power | 5V micro USB | |||
